SG90 Servo Motor

The SG90 Servo Motor is a compact, lightweight, and reliable micro servo motor designed for precise angular position control in electronic and robotic applications. It provides accurate movement control through PWM (Pulse Width Modulation) signals, making it ideal for projects that require controlled rotation and positioning.

With its small size and low power consumption, the SG90 servo motor is widely used in Arduino, ESP32, Raspberry Pi, robotics, and automation projects. It is suitable for controlling robotic arms, steering mechanisms, camera mounts, smart devices, and other small mechanical systems.

The SG90 features a durable plastic gear system and comes with mounting accessories, allowing easy installation and integration into various prototype and educational projects.

Key Features:

1. Compact micro servo motor design

2. Precise position control using PWM signal

3. Lightweight and easy to install

4. Low power consumption

5. Includes servo horns and mounting accessories

6. Compatible with Arduino, ESP32, Raspberry Pi, and microcontrollers

7. Reliable performance for robotics and automation projects

8. Suitable for beginners and professional developers

Technical Specifications:

1. Model: SG90

2. Operating voltage: 4.8V–6V DC

3. Rotation angle: Approximately 180°

4. Control method: PWM signal

5. Operating speed: About 0.1 seconds/60° (at 4.8V)

6. Stall torque: Approximately 1.8 kg·cm (at 4.8V)

7. Gear type: Plastic gears

8. Connector type: 3-wire servo cable

   1. Red: VCC (+)

   2. Brown/Black: GND (-)

   3. Orange/Yellow: Signal

Applications:

1. Robotic arm projects

2. Arduino and ESP32 projects

3. RC models and vehicles

4. Camera positioning systems

5. Smart door lock systems

6. Small automation mechanisms

7. Educational robotics projects

8. IoT and embedded system applications
