Home / Wireless Communication Modules / SIM800C GSM GPRS Module
SIM800C GSM GPRS Module

SIM800C GSM GPRS Module

SKUGSM0001
AvailabilityIn Stock
13,000 RWF12,500 RWF

7-day returns on unused items · Faulty on arrival? We replace it. Returns & warranty

DESCRIPTION

The SIM800C GSM/GPRS Module is a compact quad-band GSM module that enables microcontrollers such as Arduino, ESP8266, and ESP32 to communicate over the cellular network. It can send and receive SMS messages, make voice calls, and transmit data using GPRS.

SIM800C Specifications

Feature

Description

Module

SIM800C GSM/GPRS

Network

GSM/GPRS Quad-Band (850/900/1800/1900 MHz)

Supply Voltage

3.4V–4.4V DC (4.0V recommended)

Operating Current

20–30 mA (idle), up to 2 A during transmission bursts

Communication

UART (Serial)

Baud Rate

9,600 bps (default, configurable)

SIM Card

Micro-SIM (depends on module version)

Antenna

External GSM antenna


Features

  1.  Send and receive SMS
  2.  Make and receive voice calls
  3.  GPRS internet connectivity
  4. TCP/IP, HTTP, FTP support
  5.  Works with GPS modules (when paired externally)
  6.  Low power and sleep modes
  7. Quad-band operation for worldwide GSM networks

Pin Configuration

Pin

Function

VCC

3.4–4.4V power input

GND

Ground

TXD

Serial transmit

RXD

Serial receive

RST

Reset pin

NET

Network status indicator

MIC+/MIC?

Microphone input

SPK+/SPK?

Speaker output
